Features & Specifications

• Sensor
  • Type: Uncooled VOx Infrared Detector, 8 to 14μm
  • Resolution: 640×512@12μm
  • NETD: 20mK
  • Frame rate: 50 Hz
• Lens
  • Objective lens: 50mm, F1.0
  • Field of view: 8.8°×7.0°
  • FOV m@100m: 15×12
  • Magnification: 3.0x~23.6x
  • Detection range: 2600m/2800yd
• Display
  • Display type: 0.49'' AMOLED 1440×1080
  • Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
  • Eyepiece: Eye relief: 48 mm; Diopter ± 4; Zoom: 14x
• Hardware
  • Laser rangefinder: 1500m/1630yd
  • WIFI: 2.4G
  • Interface: USB Type-C; Micro HDMI
  • Tube diameter: Standard 30 mm
  • Others: Microphone, Bluetooth
• System
  • Recording function: Photo/Video (Audio recording included)
  • Memory capacity: 128GB
• Power
  • Battery type: Single 18650 battery (built-in) and customized battery (external)
  • Operating time: 12 hours
• Environmental
  • Operating temp.: -30°C to 50°C / -22°F to +122°F
  • Recoil Rating: .300 Win Mag
  • Shock: 800G at 1ms half sine pulse (as per IEC60068-2-27)
  • Encapsulation: IP67
• Physical
  • Weight (g/oz): 1171/41.31
  • Size (mm/in): 381×106×99/15.00×4.17×3.90
